Transducer-Plates

Customized solutions for assembly in process tanks made of stainless steel and plastic

Transducer plates made of stainless steel are available for bottom (or side wall) mounting in a plastic or stainless-steel tank. For the use in plastic process tanks a PFA coating of the transducer can be offered.

The available standard sizes are for 4" / 6" / 8" and 12" substrates, but can be also customized to different sizes. For this, the cut out area in the bottom of the tank is defined together and the transducer can then be mounted by screwing-in or welding-in. This way, a seamless and compact integration is possible.

Application:
Cleaning of substrates and semiconductor wafers with 100 mm, 150 mm, 200 mm and 300 mm in Single- or Dual-Carrier.



Example pictures below:
See some examples of how the transducer plates can be integrated in different tank formats. Raise your individual request here.
